Engineering Clamps
Industrial Clamps
Petron Thermoplast LLC is a leading supplier and manufacturer of industrial clamps in the UAE, offering a wide range of pipe clamps, hose clamps, and tubing support systems designed for durability, reliability, and easy installation.
Our industrial clamps are manufactured using high-quality thermoplastics and metals such as PP, PA (Nylon), PVC, Stainless Steel, and Aluminium, ensuring superior resistance to vibration, corrosion, and high pressure. Whether it’s for chemical processing, oil & gas, HVAC, or water treatment systems, Petron Thermoplast provides custom-engineered clamp solutions that ensure secure and long-lasting pipe installations.
Clamps are mechanical fastening devices used to secure pipes, tubes, hoses, or cables in industrial systems. They play a vital role in preventing vibration, movement, and stress on piping connections. Petron Thermoplast’s clamps are engineered for maximum grip strength, easy assembly, and long-term service even in aggressive industrial environments.
| Type of Clamp | Material Options | Features | Typical Applications |
|---|---|---|---|
| Standard Pipe Clamps | PP, PA, PVC, SS | Vibration damping, corrosion resistance | General piping systems |
| Heavy-Duty Clamps | Aluminium, SS, Reinforced Nylon | For high-pressure lines | Hydraulic & pneumatic systems |
| Twin Clamps | PP, PA | Dual-line support | Parallel pipe installations |
| Cushion Clamps | Rubber-lined Steel | Noise reduction, anti-vibration | HVAC & water systems |
| Tube Clamps (DIN 3015) | PP, PA, Aluminium | Standardized modular design | Chemical and oil industries |
| U-Bolt Clamps | Galvanized / SS | Simple and strong | Pipe and conduit mounting |
| Saddle Clamps | PVC, Steel | Secure anchoring | Plumbing and irrigation |
| Split-Type Clamps | PP, PA | Quick assembly/disassembly | Laboratory and process lines |
| Pipe Outer Diameter (mm) | Clamp Group | Width (mm) | Height (mm) | Screw Size (mm) |
|---|---|---|---|---|
| 6 – 18 | Group 1 (Light Series) | 30 | 20 | M6 |
| 19 – 30 | Group 2 (Heavy Series) | 40 | 30 | M8 |
| 31 – 42 | Group 3 (Twin or Heavy Series) | 50 | 40 | M8 / M10 |
| 43 – 60 | Group 4 | 60 | 50 | M10 |
| 61 – 90 | Group 5 (Double Body) | 80 | 65 | M12 |
| 91 – 120 | Group 6 (Heavy-Duty) | 100 | 80 | M12 / M14 |
| Property | Standard PC | UV-Stabilized PC | Flame-Retardant PC |
|---|---|---|---|
| Density (g/cm³) | 1.20 | 1.20 | 1.20 |
| Tensile Strength (MPa) | 65 | 65 | 65 |
| Flexural Modulus (GPa) | 2.0 | 2.0 | 2.0 |
| Elongation at Break (%) | 120 | 120 | 120 |
| Impact Strength (kJ/m²) | 60 | 60 | 60 |
| Service Temperature (°C) | -40 to 135 | -40 to 135 | -40 to 135 |
| Moisture Absorption (%) | 0.3 | 0.3 | 0.3 |
| Chemical Resistance | Good | Good | Good |
| Optical Clarity | Excellent | Excellent | Moderate |
| Machinability | Excellent | Excellent | Excellent |
Key Features of Petron Thermoplast Clamps
- Designed as per DIN 3015 and ISO standards
- High mechanical strength and vibration absorption
- Resistant to corrosion, UV, and chemicals
- Available in single, twin, and multi-line configurations
- Quick installation with mounting plates and bolts
- Noise and shock reduction properties
- Wide range of materials and sizes for different applications
- Suitable for high-pressure and high-temperature systems
Our clamps are used across a wide range of industrial and commercial sectors:
Chemical Processing Plants
Oil & Gas Refineries
Water & Wastewater Treatment Plants
Hydraulic and Pneumatic Systems
HVAC and Firefighting Systems
Marine & Offshore Installations
Power Generation Facilities
Pharmaceutical and Food Processing Units
Automotive Assembly Lines
Industrial Clamps are used in a wide range of industrial applications requiring mechanical precision, dimensional accuracy, and durability:
High durability and long service life
Resistance to vibration, corrosion, and harsh chemicals
Lightweight yet strong materials
Quick installation and maintenance
Reduced system noise and wear
Suitable for both indoor and outdoor applications
Modular design for flexibility
Compliant with DIN, ISO, ASTM, and BS standards
We are a leading industrial plastics supplier in the UAE, committed to delivering excellence in product quality and customer satisfaction.
Wide range of metal
Custom cut-to-size
and fabrication services
Certified quality
ISO and FDA-approved materials
Ready stock available
for quick supply
On-time delivery
across UAE, GCC, and Africa
Expert technical support
for material selection
Customization & Processing Options
Petron Thermoplast LLC offers full customization options to suit your exact project needs
- CNC machining and turning
- Laser cutting and routing
- Precision milling and drilling
- Thermoforming and bending
- Edge finishing and polishing
- Custom sheet thickness and dimensions
- Prototype and batch production services
All Industrial Clamps supplied by Petron Thermoplast LLC undergo stringent quality testing as per ASTM, ISO, and DIN standards to ensure performance and reliability.
| Aspect | Available Options |
|---|---|
| Material | PP, PA6, PVC, PVDF, Aluminium, Stainless Steel |
| Clamp Type | Standard, Twin, Heavy-Duty, Cushion, Split |
| Size Range | 6mm to 120mm OD |
| Mounting Accessories | Base plates, cover plates, bolts, washers |
| Color | Green, Black, Grey, Natural, Custom |
| Thread Type | Metric / Imperial |
| Surface Finish | Galvanized, polished, anodized, or coated |
| Special Requirements | Anti-static, UV-resistant, high-temperature grades |
| Test Type | Standard | Purpose |
|---|---|---|
| Vibration & Shock Test | DIN 3015 | Ensures vibration damping capability |
| Tensile & Compression Test | ISO 527 | Measures mechanical strength |
| Thermal Resistance Test | ASTM D648 | Confirms temperature performance |
| Chemical Resistance Test | ASTM D543 | Ensures durability in corrosive environments |
| Dimensional Accuracy | ISO 2768 | Confirms consistent manufacturing |
| Salt Spray Corrosion Test | ASTM B117 | Ensures outdoor weather performance |
Chemical Processing
Water Treatment
HVAC & Fire Protection
Oil & Gas
Food & Beverage
Pharmaceuticals
Marine & Offshore
Power Generation
Infrastructure & Utilities
Serving All Emirates in the UAE
We supply and deliver PVDF material solutions to all major regions across the UAE, including:
- Dubai
- Abu Dhabi
- Sharjah
- Ajman
- Fujairah
- Ras Al Khaimah
- Umm Al Quwain
No matter your location or project size, we ensure on-time delivery and consistent product quality.
Conclusion
At Petron Thermoplast LLC, we offer robust and precision-engineered clamps that ensure the secure and vibration-free installation of your piping systems. Our plastic and metal clamps combine strength, flexibility, and resistance to harsh conditions, making them ideal for industrial and commercial applications.
With a wide selection of materials, types, and customization options, Petron Thermoplast stands as the most trusted clamp supplier in the UAE, ensuring reliability, safety, and performance in every project.
We use Polypropylene (PP), Polyamide (PA), PVC, Aluminium, and Stainless Steel depending on the application and environment.
Yes, all our pipe and tube clamps conform to DIN 3015 (Light, Twin, and Heavy Series) standards.
Absolutely. We offer custom sizes, materials, and mounting accessories upon request.
Yes, our heavy-duty and aluminium clamps are designed for hydraulic and pneumatic systems with high pressure and vibration.
Yes, we supply complete clamp sets including top plate, base plate, bolts, and washers.
Our clamps are used in chemical, oil & gas, HVAC, water treatment, marine, and food industries.
Yes, we provide export services to GCC, Africa, and Asia with all necessary documentation.
Because we deliver premium quality, tested, and durable clamps with fast delivery and expert support.
