PVDF Materials
Petron Thermoplast is a trusted supplier of premium PVDF (Polyvinylidene Fluoride) sheets, rods, and custom-machined components across the UAE and India. Our PVDF materials are engineered for industries that demand exceptional chemical resistance, high purity, and outstanding mechanical strength. They are widely used in chemical processing, water treatment, food & beverage, marine engineering, and electronics manufacturing, where long service life and compliance with global standards are essential.
More About
PVDF (Polyvinylidene Fluoride) is a semi-crystalline, high-performance thermoplastic with a rare combination of properties—chemical inertness, high mechanical integrity, and thermal stability. Unlike commodity plastics, PVDF thrives in harsh environments with aggressive chemicals, strong UV exposure, and wide temperature variations.
PVDF Materials
- Resistance to concentrated acids, bases, halogens, and organic solvents
- Service temperature range: -40°C to +150°C
- High tensile strength, rigidity, and dimensional stability
- UV and gamma radiation resistance for outdoor and nuclear applications
- FDA compliance for food and pharmaceutical equipment
Comparison with Alternatives:
- PTFE: Comparable chemical resistance, but PVDF has superior strength and rigidity.
- Polypropylene (PP): PVDF offers higher temperature endurance and mechanical reliability.
- PEEK: PVDF is more cost-effective, though PEEK can withstand higher continuous use temperatures.
| Property | Value | Standard / Test Method |
|---|---|---|
| Density | 1.78 g/cm³ | ASTM D792 |
| Tensile Strength | 45 – 55 MPa | ASTM D638 |
| Elongation at Break | 20 – 50% | ASTM D638 |
| Shore Hardness (D) | 75 – 80 | ASTM D2240 |
| Service Temperature | -40°C to +150°C | ASTM D648 |
| Chemical Resistance | Excellent (acids, bases, solvents) | ASTM D543 |
| Water Absorption (24h) | < 0.04% | ASTM D570 |
| Flammability | UL94 V-0 | UL 94 |
| FDA Compliance | Yes | FDA 21 CFR |
| UV Resistance | Excellent | ISO 4892 |
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Our PVDF sheets and rods undergo rigorous laboratory testing to ensure compliance with international standards for industrial performance
Tensile Testing (ASTM D638)
Strength 45–55 MPa, elongation 20–50%.
Hardness Testing (ASTM D2240)
Shore D hardness of 75–80.
Heat Deflection (ASTM D648)
Stable from -40°C to +150°C.
Chemical Immersion (ASTM D543)
Resistant to acids, bases, solvents.
Flammability (UL 94)
V-0 self-extinguishing.
UV Resistance (ISO 4892)
Proven long-term outdoor stability.
Water Absorption (ASTM D570)
< 0.04% uptake after 24h.
Mechanical Properties
Tensile Strength: 45–55 MPa (ASTM D638)
Elongation at Break: 20–50% (ASTM D638)
Shore Hardness (D): 75–80 (ASTM D2240)
Rigidity: High dimensional stability under load
Wear Resistance: Good for sliding & bearing applications
Impact Resistance: Maintains toughness in cryogenic
Thermal Properties
Service Temperature Range: -40°C to +150°C (ASTM D648)
Heat Deflection Temperature: Up to 150°C
Melting Point: ~177°C
Thermal Conductivity: 0.19 W/m·K
Cryogenic Performance: Remains ductile below -40°C
Flammability: UL 94 V-0 rating
Chemical Properties
Excellent vs Acid, bases, halogens, solvents (ASTM D543)
Oxidation Resistance: Very high; superior to PP or Nylon
Moisture Absorption: < 0.04% (ASTM D570)
Chlorine & Bromine Resistance: Outstanding
Aging Resistance: Long-term dimensional and mechanical stability
Electrical Properties
Dielectric Strength: 17–22 kV/mm (ASTM D149)
Volume Resistivity: > 10¹⁴ Ω·cm
Dielectric Constant: 7.5–8.5
Dissipation Factor: Low, minimizing energy loss
Electrical Insulation: Stable under humidity and temperature extremes
Advantages & Benefits
- Superior chemical resistance to strong acids, bases, and halogens
- Lightweight yet highly durable for demanding conditions
- Simple to machine, weld, and thermoform
- Excellent outdoor weatherability and UV stability
- FDA-compliant and suitable for sanitary applications
- Long service life reduces maintenance downtime
- Cost-effective vs. ultra-high-performance polymers like PEEK
- Excellent electrical insulation performance
PVDF sheets and rods are widely used in
Chemical Processing Plants
Pumps, seals, gaskets, tanks, and valves
Food & Beverage
Sanitary piping, conveyor parts, processing equipment
Water Treatment & Desalination
Filtration housings, membranes, fittings
Marine Industry
Saltwater-resistant parts and protective linings
Oil & Gas
Flow handling, offshore pipeline protection, pump housings
Electronics Manufacturing
Semiconductor process tanks, wafer cleaning tools
General Engineering
Precision machined parts, gears, bushings, and bearings
| Property | PVDF | PTFE | PP | PEEK |
|---|---|---|---|---|
| Strength & Stiffness | High | Low | Medium | Very High |
| Wear Resistance | Good | Fair | Good | Excellent |
| Chemical Resistance | Excellent | Excellent | Good | Very Good |
| Heat Resistance | High | High | Medium | Very High |
| Cost Range | Moderate | High | Low | Very High |
| Water Absorption (24h) | ||||
| Tensile Strength | ★★★★☆ (45–55 MPa) | ★★☆☆☆ (20–30 MPa) | ★★★☆☆ (30–35 MPa) | ★★★★★ (90–100 MPa) |
| Rigidity / Stiffness | High | Low | Medium | Very High |
| Wear Resistance | Good | Fair | Good | Excellent |
| Chemical Resistance | Excellent | Excellent | Good | Very Good |
| Temperature Range | -40°C to +150°C | -200°C to +260°C | 0°C to +100°C | -50°C to +250°C |
| UV Resistance | Excellent | Poor | Fair | Very Good |
| Water Absorption | < 0.04% | < 0.01% | 0.01 – 0.03% | 0.1 – 0.2% |
| FDA Compliance | Yes | Yes | Limited | Yes |
| Cost Range | Moderate | High | Low | Very High |
Serving All Emirates in the UAE
We supply and deliver PVDF material solutions to all major regions across the UAE, including:
- Dubai
- Abu Dhabi
- Sharjah
- Ajman
- Fujairah
- Ras Al Khaimah
- Umm Al Quwain
No matter your location or project size, we ensure on-time delivery and consistent product quality.
- Strong presence in UAE and India with a global client base
- Large stock inventory for fast fulfillment
- Technical expertise in polymer selection and design support
- Competitive pricing backed by global sourcing networks
- Full custom machining and fabrication services
We stock PVDF sheets up to 100 mm thick and rods from Ø6 mm to Ø300 mm. Custom colors and grades can be sourced upon request.
Yes, we offer precision machining services including cutting, milling, drilling, welding, and fabrication.
Standard sizes are stocked for immediate dispatch. Custom orders typically ship within 7–14 working days.
All PVDF materials comply with ASTM, ISO, FDA, and RoHS standards.
Contact our technical sales team via our website or call us directly.
