Engineering Plastic Solution
PTFE Coatings
At Petron Thermoplast LLC, we specialize in industrial-grade PTFE coatings (commonly known as Teflon coatings), providing exceptional non-stick, anti-friction, and chemical-resistant protection for a wide range of industrial surfaces. As one of the leading PTFE coating suppliers and applicators in the UAE, we deliver precision-engineered coating services that enhance the durability, performance, and service life of your equipment and components — backed by fast delivery, expert fabrication, and ISO-certified quality.
Whether you need PTFE coatings for valves, fittings, gaskets, tanks, or machined parts, Petron Thermoplast ensures flawless adhesion, uniform coating thickness, and long-lasting resistance to extreme environments.
More About
PTFE (Polytetrafluoroethylene) is a high-performance fluoropolymer known for its exceptionally low coefficient of friction, high-temperature resistance, and chemical inertness. When applied as a coating, PTFE provides a non-stick, corrosion-resistant, and electrically insulating layer that protects metal, plastic, and composite components from wear, corrosion, and fouling.
Our PTFE coating process includes advanced techniques such as electrostatic spraying, fluidized bed coating, and sintering to ensure superior adhesion and finish across a wide variety of substrates.
Range of Products
| Property | PTFE | FEP | PFA | ETFE |
|---|---|---|---|---|
| Max Temperature | 260°C | 200°C | 260°C | 150°C |
| Chemical Resistance | Excellent | Excellent | Outstanding | Very Good |
| Non-Stick Properties | Excellent | Excellent | Excellent | Good |
| Hardness | Medium | Soft | Medium | High |
| Transparency | Opaque | Clear | Clear | Clear |
| UV Resistance | High | Medium | High | Excellent |
| Typical Thickness | 15–80 μm | 20–100 μm | 20–100 μm | 100–1000 μm |
Comparision
| Component Type | Typical Thickness (μm) | Maximum Temperature (°C) | Coating Process |
|---|---|---|---|
| Valves & Fittings | 20–60 | 250 | Spray Coating |
| Tanks & Vessels | 80–150 | 260 | Fluidized Bed Coating |
| Gaskets & Seals | 15–50 | 260 | Dip Coating |
| Bearings & Bushings | 30–100 | 280 | Electrostatic Coating |
| Industrial Equipment | 50–200 | 260 | Fusion Bonded Coating |
Additional Chart
| Diameter (mm) | Length (mm) | Grades |
|---|---|---|
| 6 – 20 | 1000 | Standard, Transparent, UV-Stabilized |
| 21 – 50 | 1000 | Standard, Transparent, UV-Stabilized, Black |
| 51 – 100 | 1000 | Standard, Transparent, Flame-Retardant |
| 101 – 200 | 1000 | Standard, Black, Flame-Retardant |
| Custom Sizes | On Request | All Grades |
Key Features of PTFE Coatings
- Extreme chemical resistance to acids, bases, and solvents
- Non-stick and anti-fouling surface properties
- Low coefficient of friction (0.05–0.10) for smooth operation
- Excellent electrical insulation and dielectric properties
- High temperature stability up to 260°C continuous
- Hydrophobic and moisture-resistant surface
- UV, corrosion, and oxidation resistance
- Long-lasting performance in aggressive environments
- Food-safe and FDA-compliant options available
Applications
PTFE Coatings from Petron Thermoplast LLC are used across a wide range of industries due to their strength, durability, and versatility.
Chemical Industry
Lining for reactors, pumps, valves, and pipes
Food Processing
Non-stick surfaces for molds and trays
Oil & Gas Industry
Corrosion protection for fittings and valves
Pharmaceutical Sector
Cleanroom components and processing equipment
Automotive Industry
Bearings, seals, and moving parts
Textile and Paper Industry
Rollers and guides with anti-stick surfaces
Electrical and Electronics
Insulation coatings for wiring and sensors
Marine Industry
Anti-corrosion and anti-fouling surfaces
Advantages
PTFE Coating are used in a wide range of industrial applications requiring mechanical precision, dimensional accuracy, and durability:
High Thermal Resistance
Superior Chemical Stability
FDA-Approved Options
Non-Stick Performance
Low Maintenance and Easy Cleaning
Reduced Friction
Electrical Insulation
Extended Equipment Life
Why Choose Us
We are a leading industrial plastics supplier in the UAE, committed to delivering excellence in product quality and customer satisfaction.
Wide range of metal
Custom cut-to-size
and fabrication services
Certified quality
ISO and FDA-approved materials
Ready stock available
for quick supply
On-time delivery
across UAE, GCC, and Africa
Expert technical support
for material selection
Customization & Processing Options
Petron Thermoplast LLC offers full customization options to suit your exact project needs
- CNC machining and turning
- Laser cutting and routing
- Precision milling and drilling
- Thermoforming and bending
- Edge finishing and polishing
- Custom sheet thickness and dimensions
- Prototype and batch production services
Compliance Standard
All PTFE Coatings supplied by Petron Thermoplast LLC undergo stringent quality testing as per ASTM, ISO, and DIN standards to ensure performance and reliability.
| Test Name | Standard | Purpose |
|---|---|---|
| Adhesion Test | ASTM D3359 | Ensures coating bonds effectively to the substrate |
| Thickness Measurement | ISO 2808 | Verifies uniform layer application |
| Dielectric Strength Test | ASTM D149 | Confirms electrical insulation performance |
| Thermal Aging Test | ISO 11357 | Evaluates performance at elevated temperatures |
| Chemical Resistance Test | ISO 2812 | Checks compatibility with acids, alkalis, solvents |
| Friction Coefficient Test | ASTM D2240 | Measures anti-friction performance |
| Salt Spray Test | ASTM B117 | Evaluates corrosion resistance for marine use |
Industries
Chemical & Petrochemical Plants
Oil & Gas Sector
Food & Beverage Industry
Water Treatment & Desalination
Marine & Offshore
Automotive & Aerospace
Pharmaceutical Manufacturing
Electronics & Electrical
HVAC & Environmental Systems
Serving All Emirates in the UAE
We supply and deliver PVDF material solutions to all major regions across the UAE, including:
- Dubai
- Abu Dhabi
- Sharjah
- Ajman
- Fujairah
- Ras Al Khaimah
- Umm Al Quwain
No matter your location or project size, we ensure on-time delivery and consistent product quality.
Conclusion
PTFE coatings are the gold standard for non-stick, chemical-resistant, and high-performance surface protection. At Petron Thermoplast LLC, we combine advanced coating technologies, skilled craftsmanship, and world-class materials to deliver superior PTFE coating solutions for industrial and commercial applications across the UAE.
Whether you need anti-corrosion PTFE coatings for chemical tanks or non-stick coatings for mechanical components, we guarantee precision, reliability, and long-lasting protection. Trust Petron Thermoplast LLC – the leading PTFE Coating Supplier and Service Provider in UAE.
PTFE coatings are used to provide non-stick, anti-corrosive, and low-friction surfaces in industrial and manufacturing equipment.
PTFE coatings can withstand continuous temperatures up to 260°C and intermittent exposure up to 300°C.
Yes. FDA-approved PTFE coatings are safe for use in food processing and pharmaceutical applications.
Typical thickness ranges from 15 to 100 microns, depending on application and process.
Yes. PTFE coatings adhere well to metals, ceramics, glass, and selected plastics after proper surface preparation.
Absolutely. PTFE is inert to most acids, alkalis, and organic solvents, making it ideal for chemical processing.
Yes. We offer various colors and finishes (matte, glossy, textured) as per your project specifications.
Yes, we provide fast UAE delivery and export services with full technical documentation.
