Engineering Plastic
Acetal Tubes
Petron Thermoplast LLC is a trusted supplier of premium Acetal (Delrin) Tubes in the UAE, providing durable, precision-engineered plastic tubing for industrial, mechanical, and chemical applications. Known for its excellent machinability, dimensional stability, and high strength, Acetal Tube is a top choice for applications requiring low friction, wear resistance, and long service life.
We stock Acetal Homopolymer (Delrin®) and Acetal Copolymer tubes in a wide range of sizes, grades, and colors, all conforming to international quality standards. Whether you need tubing for mechanical bushings, gears, fluid systems, or precision components, Petron Thermoplast offers fast delivery across UAE and customized production for specific needs.
More About
Acetal Tube, also known as Delrin Tube, is a semi-crystalline thermoplastic polymer derived from polyoxymethylene (POM). It is known for its exceptional rigidity, dimensional accuracy, and low coefficient of friction. Acetal combines metal-like strength with the lightness and corrosion resistance of plastic, making it an ideal material for engineering and mechanical applications.
At Petron Thermoplast LLC, our Acetal Tubes are manufactured using advanced extrusion processes to ensure tight tolerances, smooth finishes, and uniform wall thickness for high-performance applications in UAE industries.
Tubes Range
| Type | Description | Typical Uses |
|---|---|---|
| Acetal Homopolymer (Delrin®) | High mechanical strength, stiffness, and fatigue endurance. | Precision mechanical parts, gears, bushings, valve seats. |
| Acetal Copolymer | Improved chemical resistance and dimensional stability. | Fluid handling, pump components, automotive parts. |
| Glass-Filled Acetal Tube | Enhanced stiffness and wear resistance under load. | High-stress mechanical applications. |
| Lubricated (PTFE-Filled) Acetal Tube | Self-lubricating for reduced friction and wear. | Bearings, sliding mechanisms, conveyor parts. |
| Conductive/ESD Acetal Tube | Prevents static charge build-up in sensitive environments. | Electronic and semiconductor equipment. |
Comparision Data
| Property | Acetal Homopolymer | Acetal Copolymer | Glass-Filled Acetal |
|---|---|---|---|
| Density (g/cm³) | 1.42 | 1.41 | 1.57 |
| Tensile Strength (MPa) | 72 | 65 | 90 |
| Elongation at Break (%) | 35 | 40 | 10 |
| Flexural Modulus (MPa) | 3000 | 2900 | 4500 |
| Continuous Service Temp (°C) | -40 to +100 | -40 to +100 | -40 to +120 |
| Coefficient of Friction | 0.2 | 0.25 | 0.3 |
| Water Absorption (24h %) | 0.2 | 0.2 | 0.3 |
| Machinability | Excellent | Excellent | Good |
| Chemical Resistance | Good | Excellent | Good |
Measurement Chart
| Outer Diameter (mm) | Inner Diameter (mm) | Wall Thickness (mm) | Standard Length (mm) |
|---|---|---|---|
| 6 | 4 | 1 | 1000 |
| 10 | 8 | 1 | 1000 |
| 12 | 9 | 1.5 | 1000 |
| 16 | 12 | 2 | 1000 |
| 20 | 16 | 2 | 1000 |
| 25 | 19 | 3 | 1000 |
| 32 | 25 | 3.5 | 1000 |
| 40 | 32 | 4 | 1000 |
| 50 | 40 | 5 | 1000 |
| 63 | 52 | 5.5 | 1000 |
| Custom Sizes | On Request | On Request | On Request |
Key Features of Acetal Tube
- High mechanical strength and rigidity
- Excellent wear and abrasion resistance
- Very low coefficient of friction
- Dimensional stability and machinability
- Resistance to moisture, fuels, and solvents
- High fatigue and creep resistance
- Excellent electrical insulating properties
- FDA-approved for food contact (select grades)
- Withstands continuous temperatures up to 100°C
- Long service life even under mechanical stress
Applications
Acetal Tubes from Petron Thermoplast LLC are used across a wide range of industries due to their strength, durability, and versatility.
High strength-to-weight ratio
Excellent machinability — ideal for CNC turning
Resistant to hydrocarbon fuels and chemicals
Low moisture absorption — retains mechanical integrity
Non-corrosive and non-conductive
Smooth surface finish enhances flow and reduces friction
Noise-reducing alternative to metal components
Available in natural, black, and custom colors
Advantages
Acetal Tubes are used in a wide range of industrial applications requiring mechanical precision, dimensional accuracy, and durability:
Extremely impact-resistant and durable
High dimensional stability under extreme conditions
Chemical and UV resistance ensures long life
Transparent rods for visual and display applications
Flame-retardant grades for electrical and industrial safety
Machinable and customizable for industrial parts fabrication
Cost-effective alternative to metal for many applications
Low maintenance and high performance in demanding environments
Why Choose Us
We are a leading industrial plastics supplier in the UAE, committed to delivering excellence in product quality and customer satisfaction.
Wide range of metal
Custom cut-to-size
and fabrication services
Certified quality
ISO and FDA-approved materials
Ready stock available
for quick supply
On-time delivery
across UAE, GCC, and Africa
Expert technical support
for material selection
Customization & Processing Options
Petron Thermoplast LLC offers full customization options to suit your exact project needs
- CNC machining and turning
- Laser cutting and routing
- Precision milling and drilling
- Thermoforming and bending
- Edge finishing and polishing
- Custom sheet thickness and dimensions
- Prototype and batch production services
testing Standards
All Polycarbonate Rods supplied by Petron Thermoplast LLC undergo stringent quality testing as per ASTM, ISO, and DIN standards to ensure performance and reliability.
| Property / Test | Standard / Method |
|---|---|
| Density | ASTM D792 |
| Tensile Strength | ASTM D638 |
| Flexural Modulus | ]ASTM D790 |
| Impact Strength | ASTM D256 |
| Hardness (Rockwell M) | ASTM D785 |
| Coefficient of Friction | ASTM D1894 |
| Heat Deflection Temperature | ASTM D648 |
| Chemical Resistance | ASTM D543 |
| Food Contact Safety | FDA 21 CFR 177.2470 |
| Dimensional Accuracy | ISO 2768 |
Industries
Automotive and Transportation
Electrical and Electronics
Water and Fluid Handling
Food and Beverage Processing
Mechanical and Industrial Engineering
Robotics and Automation
Oil & Gas Equipment Manufacturing
Serving All Emirates in the UAE
We supply and deliver PVDF material solutions to all major regions across the UAE, including:
- Dubai
- Abu Dhabi
- Sharjah
- Ajman
- Fujairah
- Ras Al Khaimah
- Umm Al Quwain
No matter your location or project size, we ensure on-time delivery and consistent product quality.
Conclusion
Petron Thermoplast LLC offers high-quality Acetal (Delrin) Tubes designed for strength, precision, and durability in demanding environments. Our Acetal Tubes combine metal-like mechanical performance with the lightweight, non-corrosive advantages of thermoplastics, making them ideal for engineering, fluid handling, and automation systems.
With customization, certified quality, and fast delivery across UAE, Petron Thermoplast is your trusted partner for engineering plastic solutions.
Acetal Tube is made from polyoxymethylene (POM) resin — available as Delrin Homopolymer or Copolymer — known for strength and rigidity.
Acetal Tubes can operate continuously between -40°C and +100°C, depending on the grade.
Yes. FDA-approved grades are available for food, beverage, and pharmaceutical applications.
Absolutely. Acetal provides metal-like stiffness and low friction, making it an ideal substitute in lightweight designs.
Yes. We can provide custom inner and outer diameters, wall thicknesses, and cut-to-size lengths based on your needs.
We offer same-day or next-day delivery for standard sizes and quick lead times for custom orders.
Yes. Petron Thermoplast provides export services to GCC, Africa, and Asia, including all necessary certifications.
